Custom Prefab Warehouse High Strength Bolts Connected Prefabricatd Steel Structure Warehouse
Steel Structure Features:
High Strength-to-Weight Ratio – Steel offers exceptional strength while being relatively lightweight, allowing for large spans and reduced foundation loads.
Durability & Longevity – Resistant to corrosion (when properly treated) and environmental factors, steel structures have a long service life with minimal maintenance.
Design Flexibility – Steel can be molded into various shapes, enabling innovative and complex architectural designs while maintaining structural integrity.
Speed of Construction – Prefabricated steel components allow for fast assembly, reducing project timelines compared to traditional materials.
Sustainability – Steel is 100% recyclable, making it an eco-friendly choice that supports green building practices.
Seismic & Wind Resistance – Its ductility and ability to withstand dynamic forces make steel ideal for earthquake-prone and high-wind regions.
Cost-Effectiveness – Lower labor costs, reduced construction time, and minimal maintenance contribute to long-term economic benefits.
Fire Resistance – While steel weakens at high temperatures, fireproofing coatings enhance its performance in fire-prone scenarios.
Adaptability – Steel structures can be easily modified, expanded, or repurposed to meet changing needs.
Quality Control – Factory-manufactured steel components ensure precision and consistency, minimizing on-site errors.
| Product Application |
| Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse |
| A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding! |
| An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework. |
| SPECIFICATION FOR STEEL STRUCTURE BUILDING |
| Main Steel Frame | Steel Column & Beam | 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel |
| 2. Surface: Hot Dip Galvanized or Painted; |
| 3. Connection: All Bolts Connection; |
| Supporting System | Roof Purlin | C or Z Section Steel, Q235B |
| Wall PDoorurlin | C or Z Section Steel, Q235B |
| Bracing | Steel Rod, Q235B |
| Cross Support | Steel Rod, Q235B |
| Column Support | Angle Steel; Steel Rod; Q235B |
| Angle Brace | Angle steel,Q235B |
| Tie Bar | Steel Pipe,Q235B |
| Roof & Wall System | 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm |
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm; |
| Accessories | | Sliding; Rolled Up Door (Manual/Auto) |
| Window | Aluminum Alloy; PVC; |
| Downspout | PVC pipe; |
| Gutter | Galvanized Steel Sheet; Stainless Steel |
| Ventilator | Stainless Steel Turbine Ventilator |
| Skylight Belt | FRP or PC semi-transparent Skylight Belt |
| Flash | Color Steel Sheet |
| Fittings | Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc |
